1. Specifications
1-1. Indoor unit
Type
Wall mounted
Inverter heat pump
Model name ASHG07KMCE ASHG09KMCE ASHG12KMCE ASHG14KMCE
Power supply 230 V ~ 50 Hz
Available voltage range 198—264 V
Capacity
Cooling
Rated
kW 2.00 2.50 3.40 4.20
Btu/h 6,800 8,500 11,600 14,300
Min.—Max.
kW 0.9—3.0 0.9—3.2 0.9—3.9 0.9—4.4
Btu/h 3,100—10,200 3,100—10,900 3,100—13,300 3,100—15,000
Heating
Rated
kW 2.50 2.80 4.00 5.40
Btu/h 8,500 9,500 13,600 18,400
Min.—Max.
kW 0.9—3.4 0.9—4.0 0.9—5.3 0.9—6.0
Btu/h 3,100—11,600 3,100—13,600 3,100—18,000 3,100—20,500
Input power
Cooling
Rated
kW
0.450 0.630 0.935 1.220
Min.—Max. 0.25—1.17 0.25—1.21 0.25—1.27 0.25—1.40
Heating
Rated 0.555 0.620 0.960 1.410
Min.—Max. 0.25—1.21 0.25—1.26 0.25—1.52 0.25—1.73
Fan
HIGH
W
22.1 26.5 26.5 33.6
MED 15.1 16.0 16.0 20.0
LOW 10.0 10.0 6.4 11.8
QUIET 6.4 6.4 4.8 7.1
Current
Cooling
Rated A
2.6 3.4 4.8 5.8
Heating 3.0 3.4 5.1 6.8
EER Cooling
kW/kW
4.43 3.97 3.65 3.44
COP Heating 4.52 4.52 4.17 3.83
Sensible capacity Cooling kW 1.2 1.6 2.2 3.2
Power factor
Cooling
%
75 81 88 88
Heating 80 79 87 87
Moisture removal L/h (pints/h) 1.0 (1.8) 1.3 (2.3) 1.8 (3.2) 2.1 (3.7)
Maximum operating current *1
Cooling
A
6.5 6.5 6.5 6.5
Heating 9.0 9.0 9.0 9.0
Fan
Airflow rate
Cooling
HIGH
m
3
/h
650 700 700 770
MED 540 560 560 600
LOW 430 430 430 450
QUIET 270 270 270 280
Heating
HIGH 720 750 780 820
MED 580 610 640 660
LOW 460 470 520 520
QUIET 330 330 330 340
Type × Q'ty Crossflow fan × 1
Motor output W 27
Sound pressure level *2
Cooling
HIGH
dB (A)
38 40 40 43
MED 33 34 35 36
LOW 29 29 30 30
QUIET 20 20 20 20
Heating
HIGH 41 42 42 44
MED 35 36 38 39
LOW 31 31 33 33
QUIET 22 22 22 24
Heat exchanger type
Dimensions (H × W × D)
mm
Main1: 210 × 670 × 26.6
Main2: 112 × 670 × 20
Main1: 210 × 670 × 26.6
Main2: 112 × 670 × 20
Sub: 84 × 670 × 13.3
Fin pitch
Man1: 1.2
Main2: 1.1
Man1: 1.2
Main2: 1.1
Sub: 1.4
Rows × Stages
Main1: 2 × 10
Main2: 2 × 7
Main1: 2 × 10
Main2: 2 × 7
Sub: 1 × 4
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material Polystyrene
Color
White + Pearl white (painted)
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net
mm
270 × 834 × 215
Gross 277 × 914 × 332
Weight
Net
kg
10.0
Gross 12.5 13.0
Connection pipe
Size
Liquid
mm (in)
Ø6.35 (Ø1/4)
Gas Ø9.52 (Ø3/8)
Method Flare
Drain hose
Material PP+LLDPE
Tip diameter mm Ø13.8 (I.D.), Ø15.0 to Ø16.8 (O.D.)
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type
Wireless (Wired, Mobile app*3 [FGLair
™
] [option])
1-1. Indoor unit - (01-1) - 1. Specifications
