Fujitsu Halcyon ASU12CQ User Manual

En-2
Fig. 1 Indoor Unit
1 Operating Control Panel (Fig. 2)
2 AIR CLEANER RESET / MANUAL AUTO
button
●
Intake grill opening mechanism.
When the remote control is not available
for use, this button can be used as a
Quick-start button. However when the
Air Cleaning check function (see page 13)
is in operation, this button is used as a
reset button.
3 Indicator Lamps (Fig. 3)
4 Remote Control Signal Receiver
5 OPERATION Indicator Lamp (red)
6 TIMER Indicator Lamp (green)
●
If the TIMER indicator lamp flashes when
the timer is operating, it indicates that a
fault has occurred with the timer setting
(See Page
G Auto Restart).
7 AIR CLEAN Indicator Lamp (green)
8 SWING Indicator Lamp (orange)
9 Intake Grille (Fig. 4)
0 Air Filter
A Air Flow Direction Louver
B Right-Left Louver
(behind Air Flow Direction Louver)
C Drain Hose
D Electrical Air Cleaning Filter
Fig. 5 Outdoor Unit
E Intake Port
F Outlet Port
G Pipe Unit
Fig. 6 Remote Control Unit
H MASTER CONTROL button
I SET TEMP. / SET TIME buttons (+/-)
J Signal Transmitter
K TIMER button
L FAN CONTROL button
M START/STOP button
N AIR CLEAN button
O SET button
P SWING button
Q ACL button
R TIME ADJUST button
Rear side (Fig. 7)
S TEST RUN
● Touch the two metal contacts with a
metallic object to send the signal to
perform a test run.
● Perform a test run only when installing the
air conditioner. If the signal to perform a
test run is received during normal
operation, the air conditioner’s thermostat
will malfunction.
● If the signal to perform a test run is re-
ceived during normal operation, the unit
will switch to the test operation mode and
the indoor unit’s OPERATION and TIMER
indicator lamps will flash simultaneously.
● To stop the test operation mode, press the
START/STOP button to stop the air
conditioner.
T Remote Control Unit Display (Fig. 8)
U Transmit Indicator
V Clock Display
W Operating Mode Display
X T imer Mode Display
Y Fan Speed Display
Z Temperature Set Display
[ T imer Set Indicator
\ Temperature Set Indicator
● Refer to the folded out page on the cover.
