Removing and inst alling components
during servicing
Removing and installing the hard disk (HDD,
LIFEBOOK U757 only)
In the LIFEBO OK U757, you c an either install an M.2 module (with correspon ding M.2 adapter, see
"
Installing and removing an M.2 module", Page 76) or a standard hard disk (HDD, w ithout M.2 adapter).
Removing the hard disk
► Remove the cover, see "Remove the cover", Page 76.
For easier removal from the device, the hard disk is installed in a hard disk carrier.
1
1
2
► Pull the hard disk in the direction of the arrow (1).
► Release the connector from the hard disk (2).
► Remove the hard disk from the hard disk compartme nt.
Fujitsu 79
