30 Disassembly and Recycling Instructions CX400 M4
Disassembly and recycling
1.3 Disassembly of the server nodes
I Not all components are installed in the server nodes depending on the
configuration.
The recycling parts are valid for one server node.
1.3.1 Removing the SXM2 extension tray, SXM2 modules
and LC kit
Tools: Phillips PH2 / (+) No. 2 screw driver
Recycling parts
SXM2 extension tray, 1x SXM2 base board, 1x to 4x SXM2 modules, 2x SXM2
riser, several screws
Liquid Cooling (LC) kit: 4x LC heat sinks, tubes, tube fixation bracket, PLX
bracket
Plastic
Metal
Printed circuit
Cables
