 Disassembly Process of Outdoor Unit
Makre sure that the wires are not pinched when you close the SERVICE PANEL.
Caution
by sliding downward.
Remove the SERVICE PANEL
Remove the mounting screws.
Hooks (4 places)
(serrated)
Screws
►
Single phase type
▼
Appearance
▼
Service panel removal
Before servicing the unit,
turn the power supply switch OFF, then, do not touch electric parts for 10 minutes
due to the risk of electric shock.
Waterstage / Maintenance Manual / 2105 - EN
