• Fit the rotor into its seat, taking care with the direction of rotation indicated by the arrow (Fig. 33).
• Screw in the 6 screws to 5/7 Nm (44/62 in.lbs) (Fig. 33).
WARNING
After donning protective gloves turn the rotor clockwise and tighten the rotor fixing screws in the order illustrated in Fig. 34.
34
6.2 - ASSEMBLING THE ROTOR ON THE ISO 6-BOLTS SYSTEM
16
• Fit the rotor into its seat, taking care with the direction of rotation
indicated by the arrow (Fig. 32).
• Fit the washer (A - Fig. 32) and screw the provided lockring (B –
Fig. 32).
• Tighten the lockring to 40 Nm (354 in.lbs) using the tool UT-BB130
(C - Fig. 32 - not provided) and torque wrench (D - Fig. 32).
6.1 - ASSEMBLING THE ROTOR ON AXIAL FIXING SYSTEM
™
SYSTEMS
5/7 N.m
5/7 Nm
(44/62 in.lbs)
33
A B C D
35 N.m
A
B
C
D
40 Nm
(354 in.lbs)
32
6 -
BRAKES
®
