● Fit the Ø6.5 washer and lock nut, then tighten them
CONNECT ALL THE WIRES
Turn over the vehicle body, you can see there are connectors on A, B, C and D
Connect the A connectors first, the male connector of A is come out from the main
frame, the female connector is come out from the pedal switch.
The connectors of B are the main power wires, the male connector is come out from
the main frame, the female connector is come out from seat support.
Connectors of C and D are the steering wires, connect them as the pictures show
above.
ASSEMBLE THE BATTERY COVER AND FLAG
