FUNAI D8A-M1000DB - Page 52

1-15-3 E8GA0PIN
Notes:
Abbreviation for Active Level:
PWM -----Pulse Wide Modulation
A/D--------Analog - Digital Converter
81 OUT
LM-FWD/
REV
Loading
Motor
Control
Signal
H/L/
Hi-z
82 OUT
OUTPUT-
SELECT
Output Select H/L
83 OUT
AUDIO-
MUTE-H
Audio Mute
Control
Signal (Mute
= “H”)
H
84 -
NU Not Used
-
85 -
NU Not Used
-
86 -
NU Not Used
-
87 IN
C-FG
Capstan
Motor
Rotation
Detection
Pulse
PULSE
88 -
NU Not Used
-
89 -
NU Not Used
-
90
IN
D-PFG
Drum Motor
Phase/
Frequency
Generator
PULSE
91 -
AMPVREF
OUT
V-Ref for
CTL AMP
-
92 -
AMPVREF
in
V-Ref for
CTL AMP
-
93 -
P80/C
P80/C
Ter minal
-
94
IN/
OUT
CTL (-)
Playback/
Record
Control
Signal (-)
H/L
95
IN/
OUT
CTL (+)
Playback/
Record
Control
Signal (+)
H/L
96 -
AMPC
CTL AMP
Connected
Ter minal
-
97 -
CTL
To Monitor
for CTL AMP
Output
PULSE
98 -
AMPVcc AMPVcc
-
99 -
AVcc
A/D
Converter
Power Input/
Standard
Voltage Input
-
100 IN
AGC
IF AGC
Comparator
Signal
A/D
Pin
No.
Mark
IN/
OUT
Signal
Name
Function
Active
Level
