FUNAI D8A-M1000DB - Mechanical Parts List

20070314 1-18-1 E8GA0CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Comparison Chart of Models and Marks
Model Mark
D8A-M1000DB A
D8D-M1000DB B
Ref. No. Mark Description Part No.
A1X FRONT ASSEMBLY E8GA0ED 1VM222904
A2 TOP CASE(BLACK) E8G00ED 1VM323682
A3 CHASSIS(BLACK) E8G00ED 1VM222891
A7 BOTTOM PANEL H992URD 1VM321771
A10! A RATING LABEL E8GA0ED ----------
A10! B RATING LABEL E8GA4ED ----------
A14 BARCODE LABEL UNFIGURE E9704ED ----------
A14 A BAR CODE LABEL E8GA0ED ----------
A14 B BAR CODE LABEL E8GA4ED ----------
A21 B WARNING LABEL HG249ED ----------
A22 CHASSIS FOOT H79P9JD 0VM412315
A24 A LABEL SERIAL NO. E5441JD or ----------
A LABEL SERIAL NO. E5705JD ----------
1B1 DECK ASSEMBLY CZD014/VM25C0 N25C0FL
1B2 DVD MECHA E7 N79F0KVM N79F0KVM
2B2 TOP BRACKET H9700ED 0VM204531
2B3 LOADER HOLDER H9600UD 0VM306676
2B5 SHEILD CYLINDER H9700ED 0VM306780
2B9 CUSHION HC460ED 0VM413251
2B16 TAPE HIMELON H9206JD 0VM413956
2B18 FIBER TOP CASE HC460ED 0VM412906
2B21! LASER CAUTION LABEL H9900ED ----------
2B40 PARTITION PLATE E8B00ED 1VM424064
2B54 PLATE GROUND(RCA) H9700ED 0VM306867
2B55 PLATE GROUND(21P) H9700ED 0VM416444
2L011 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
2L012 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
2L020 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
2L021 SCREW P-TIGHT M3*12 BIND+ GBJP3120
2L022 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
2L041 SCREW P-TIGHT M3X6 BIND HEAD+
BLK
GBHP3060
2L051 SCREW P-TIGHT M3X6 BIND HEAD+ GBJP3060
2L054 SCREW P-TIGHT M3X6 BIND HEAD+ GBJP3060
2L071 SCREW P-TIGHT M3*10
WASHERHEAD+
GCJP3100
2L091 SCREW P-TIGHT M3X8 BIND HEAD+ GBCP3080
L0-9 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
PACKING
S1 A GIFT BOX CARTON E8GA0ED 1VM323751
S1 B GIFT BOX CARTON E8GA4ED 1VM323761
S2 STYROFOAM H9600UD 0VM204474E
S3 UNIT BAG E5500UD 0VM411683
S7 A 21P PAD HC463FD 0VM413384
ACCESSORIES
X1 REMOTE CONTROL UNIT NB665ED NB665ED
X2 DRY BATTERY R6P/2S or XB0M451T0001
DRY BATTERY R6UW/2S or XB0M311MS001
DRY BATTERY ES-GR6M-C XB0M571GLP01
X3 RF CORD PAL 1.2M or WPZ0122LG001
RF CABLE CC1001020012010 WPZ0122LW001
X4 ACCESSORY BAG E5795ED 0VM416059
X5 A WIRE ASSEMBLY SCART CABLE
CE1013020121410
WX1E8G00-111
X20A! A OWNERS MANUAL(NO) E8GA0ED 1VMN23483
X20A! B OWNERS MANUAL(HU) E8GA4ED 1VMN23504
X20B! A OWNERS MANUAL(SV) E8GA0ED 1VMN23484
X20B! B OWNERS MANUAL(SK) E8GA4ED 1VMN23505
X20C! A OWNERS MANUAL(FI) E8GA0ED 1VMN23485
X20C! B OWNERS MANUAL(EN) E8GA4ED 1VMN23506
X20D! A OWNERS MANUAL(DA) E8GA0ED 1VMN23486
X20D! B OWNERS MANUAL((DE) E8GA4ED 1VMN23507
X20E! A OWNERS MANUAL(ES) E8GA0ED 1VMN23487
X20E! B OWNERS MANUAL(PL) E8GA4ED 1VMN23508
X20F! A OWNERS MANUAL(PT) E8GA0ED 1VMN23488
X20F! B OWNERS MANUAL(CS) E8GA4ED 1VMN23509
X20G! A OWNERS MANUAL(DE) E8GA0ED 1VMN23489
X20G! B OWNERS MANUAL(RU) E8GA4ED 1VMN23510
X20H! A OWNERS MANUAL(IT) E8GA0ED 1VMN23490
X20H! B OWNERS MANUAL(AR) E8GA4ED 1VMN23511
X20J! A OWNERS MANUAL(EL) E8GA0ED 1VMN23491
X20J! B OWNERS MANUAL(RO) E8GA4ED 1VMN23512
X20K! B OWNERS MANUAL(BG) E8GA4ED 1VMN23513
X21 A WARRANTY CARD(EL) E8GA0ED 1VMN23492
X22 A SERVICE CENTER LIST HC2C0ED 0VMN03071D
X34 POST CARD E8G00ED 1VMN23493
X35 A HANDBILL E8G00ED 1VMN23494
X35 B HANDBILL E8G04ED 1VMN23558
Ref. No. Mark Description Part No.
