FUNAI D8A-M1000DB - Page 65

20070314 1-19-9 E8GA0EL
DVD OPEN/CLOSE CBA
SENSOR CBA
PSV CBA
POWER SUPPLY CBA
R2080 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R2081 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R2086 CHIP RES. 1/10W J 5.6k Ω or RRXAJR5Z0562
RES CHIP 1608 1/10W J 5.6k Ω RRXA562YF002
R2093 CHIP RES. 1/10W J 22k Ω or RRXAJR5Z0223
RES CHIP 1608 1/10W J 22k Ω RRXA223YF002
R2094 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
SWITCHES
SW501 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW502 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW503 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW504 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW506 LEAF SWITCH MXS01830MVP0 SSC0101MCE03
SW507 SWITCH ROTARY SSS-53MD-1 SSR0106KB004
SW601 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW602 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW603 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW604 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW605 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW2005 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW2006 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW2021 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW2022 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
MISCELLANEOUS
2B11 NEW SHIELD ASSEMBLY H9700ED 1VM420438
2B15 BUSH LED(F) H3700UD 0VM409508
2B46 ROHM HOLDER H7770JD 0VM304573
2L062 SCREW B-TIGHT M3X8 BIND HEAD+ GBHB3080
2L082 SCREW B-TIGHT M3X8 BIND HEAD+ GBHB3080
A5 JACK COVER E8B80BD 1VM323212
JK101 RGB CONNECTOR MRC-021V-03
ABS(B11
JXGL210LY006
JK751 RCA JACK 2P MSP-282V-12 NILF(B11 JXRL020LY121
JK752 RCA JACK MSP-281V42-B(B110) JXRL010LY142
JK754 RCA JACK MSP-281V40-B(B110) JXRL010LY138
JK1202 RCA JACK MSP-281V41-B(B110) JXRL010LY140
JK1401 S TYPE JACK MDC-050V-2.4 LF(B110 or JXEL040LY003
S TYPE JACK DIN-425-01 JXEL040YUQ01
Ref. No. Mark Description Part No.
JW006 FFC CABLE 27P FFC/P1.00/260 WX1E8B00-103
JW007 FFC CABLE 16P FFC/P1.00/170 WX1E8B00-101
PS502 PHOTO INTERRUPTER RPI-302C70 QPWZP1302C70
RM2001 SENSOR REMOTE RECEIVER KSM-
602LU2S or
USESJRSKK048
REMOTE RECEIVER PIC-37042LU or USESJRSKK033
REMOTE RECEIVER MIM-93M6DKF USESJRSUNT01
TP301 PCB JUMPER D0.6-P19.0 JW19.0T
TP501 PCB JUMPER D0.6-P5.0 JW5.0T
TP502 PCB JUMPER D0.6-P5.0 JW5.0T
TP503 PCB JUMPER D0.6-P6.0 JW6.0T
TP504 PCB JUMPER D0.6-P15.0 JW15.0T
TU701 TUNER UNIT TMDG9-861A UTUNPLGAL015
X301 XTAL 4.433619MHz or FXC445LLN004
XTAL 1K*044334EE FXC445LDS002
X501 XTAL 12MHz 12.000MHz or FXD126LDS002
QUARTS CRYSTAL 12.000000MHz FXD126LCHE01
X502 RESONATOR XTAL 32.768kHz QTF38-
32.768K125P15L or
FXC323LQUA03
XTAL DT38 32.768kHz FX0323LDS001
Ref. No. Mark Description Part No.
DVD OPEN/CLOSE CBA (MCV-C)
Consists of the following:
----------
SWITCHES
SW2020 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
MISCELLANEOUS
JW008 JUMPER WIRE 2P AWG26#2651/P2.0/
130
WX1H7375-001
Ref. No. Mark Description Part No.
SENSOR CBA
Consists of the following:
1VSA10047
TRANSISTORS
Q503 PHOTO TRANSISTOR PT204-6B-12 or NPWZT2046B12
PHOTO TRANSISTOR MID-32A22F NPWZ1D32A22F
Q504 PHOTO TRANSISTOR PT204-6B-12 or NPWZT2046B12
PHOTO TRANSISTOR MID-32A22F NPWZ1D32A22F
Ref. No. Mark Description Part No.
PSV CBA
Consists of the following
1VSA15613
POWER SUPPLY CBA (PSV-A)
JUNCTION CBA (PSV-B)
JACK-A CBA (PSV-C)
---------
---------
---------
Ref. No. Mark Description Part No.
POWER SUPPLY CBA (PSV-A)
Consists of the following:
---------
CAPACITORS
C013 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C014 ELECTROLYTIC CAP. 470µF/16V M CE1CMASDL471
C015 ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C017 ELECTROLYTIC CAP. 1000µF/16V M CE1CMASDL102
C018 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C020 ELECTROLYTIC CAP. 22µF/50V M CE1JMASDL220
C021 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C022 ELECTROLYTIC CAP. 470µF/35V M CE1GMASDL471
Ref. No. Mark Description Part No.
