20070314 1-19-11 E8GA0EL
JUNCTION CBA
JACK-A CBA
R1008 CARBON RES. 1/4W J 560 Ω RCX4JATZ0561
R1010 CARBON RES. 1/6W J 8.2k Ω or RCX6JATZ0822
CARBON RES. 1/4W J 8.2k Ω RCX4JATZ0822
R1011 METAL OXIDE FILM RES. 1W J 1.3 Ω or RN01JZLZ01R3
METAL OXIDE FILM RES. 1W J 1.3 Ω RN01JZPZ01R3
R1020 CHIP RES. 1/10W J 1.8k Ω or RRXAJR5Z0182
RES CHIP 1608 1/10W J 1.8k Ω RRXA182YF002
R1021 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002
R1022 CHIP RES. 1/10W J 4.7k Ω or RRXAJR5Z0472
RES CHIP 1608 1/10W J 4.7k Ω RRXA472YF002
R1023 CHIP RES.(1608) 1/10W F 2.2k Ω or RRXAFR5H0222
CHIP RES. 1/10W F 2.2k Ω or RRXAFR5Z0222
RES CHIP 1608 1/10W F 2.20k Ω RTW2201YF002
R1025 CHIP RES. 1/10W F 5.6k Ω or RRXAFR5H0562
CHIP RES. 1/10W F 5.6k Ω or RRXAFR5Z0562
RES CHIP 1608 1/10W F 5.60k Ω RTW5601YF002
R1029 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1030 CARBON RES. 1/4W J 82 Ω RCX4JATZ0820
R1031 CARBON RES. 1/4W J 82 Ω RCX4JATZ0820
R1032 CARBON RES. 1/4W G 1k Ω RCX4GATZ0102
R1035 CARBON RES. 1/6W J 1k Ω or RCX6JATZ0102
CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1036 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1037 CARBON RES. 1/6W J 10k Ω or RCX6JATZ0103
CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R1038 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1039 CARBON RES. 1/6W J 470k Ω or RCX6JATZ0474
CARBON RES. 1/4W J 470k Ω RCX4JATZ0474
R1043 METAL OXIDE FILM RES. 1W J 2.7 Ω or RN012R7ZU001
METAL OXIDE FILM RES. 1W J 2.7 Ω RN012R7DP003
R1126 CHIP RES. 1/10W J 33k Ω or RRXAJR5Z0333
RES CHIP 1608 1/10W J 33k Ω RRXA333YF002
MISCELLANEOUS
2B33 HEATSINK H9700ED 0VM416271
2L053 SCREW S-TIGHT M3X8 BIND HEAD+ GBJS3080
AC1001
!
AC CORD PE8G2CG9G0AA059 or WAE0172LW009
! AC CORD WITH A GND WIRE L0A0280-
005
WAE0172LTE06
F1001! FUSE T1.6AL/250V or PAGC20BW3162
! FUSE 50T016H 1.6A/250V PAGH20BHV162
FH1001 FUSE HOLDER MSF-015 LF (B110) or XH01Z00LY002
FUSE HOLDER DFH-001 XH01Z00RP001
FH1002 FUSE HOLDER MSF-015 LF (B110) or XH01Z00LY002
FUSE HOLDER DFH-001 XH01Z00RP001
T0011! TRANS POWER BCK-28-9993 or LTTZPE0XB001
! TRANS POWER 6708 LTTZPE0KT004
Ref. No. Mark Description Part No.
JUNCTION CBA (PSV-B)
Consists of the following:
---------
CONNECTOR
CN051A 242 SERIES CONNECTOR TUC-P14X-
B1 WHT ST
JCTUB14TG002
MISCELLANEOUS
JW001 FLAT CABLE 8P AWG26#2651/P2.0/75 WX3808S6FF07
JW002 FLAT CABLE 6P AWG26#2651/P2.0/65 WX3806S6FF06
Ref. No. Mark Description Part No.
Ref. No. Mark Description Part No.
JACK-A CBA (PSV-C)
Consists of the following:
---------
CAPACITORS
C101 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C102 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C103 ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C105 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C108 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C111 CHIP CERAMIC CAP.(1608) CH J 470pF/
50V
CHD1JJ3CH471
C119 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
DIODES
D112 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D113 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D122 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D123 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D124 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D125 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
COIL
L102 BEAD CORE ASSEMBLY E8G05ED 1VSA15550
TRANSISTORS
Q103 TRANSISTOR KTA-1266-GR-AT/P or NQS4KTA1266P
TRANSISTOR 2SA1015-GR(TE2 F T) QQS12SA1015F
RESISTORS
R107 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
R108 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
R109 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
R110 CARBON RES. 1/6W J 4.7k Ω or RCX6JATZ0472
CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R111 CARBON RES. 1/6W J 220 Ω or RCX6JATZ0221
CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R114 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R115 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R117 CARBON RES. 1/4W J 510 Ω RCX4JATZ0511
R120 CARBON RES. 1/4W J 68 Ω RCX4JATZ0680
R125 CARBON RES. 1/6W J 4.7k Ω or RCX6JATZ0472
CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R126 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
MISCELLANEOUS
JK1402 RGB CONNECTOR MRC-021V-03
ABS(B11
JXGL210LY006
JW003 FLAT CABLE 10P AWG26#2651/P2.0/190 WX3810S6FF19
JW004 FLAT CABLE 4P AWG26#2651/P2.0/190 WX3804S6FF19
