FUNAI DPVR-6600 - Waveforms

WAVEFORMS
WF3
WF2
WF3
UPPER
WF1
WF1
LOWER
TP751
TP751
TP504
UPPER
LOWER
TP504
TP301
WF4
WF6
Pin 6 of IC1403
WF5
VIDEO-C
WF7
AUDIO-L
1V 0.5ms
WF8
WF9
SPDIF 1V 0.1 µs
Pin 8 of CN1601
Pin 10 of CN1601
Pin 13 of CN1601
Pin 15 of CN1601
Pin 18 of CN1601
NOTE:
Input
VCR: COLOR BAR SIGNAL (WITH 1KHz AUDIO SIGNAL)
(WF1~WF3)
DVD: POWER ON (STOP) MODE
(WF4~WF6)
CD: 1kHz PLAY
(WF7~WF9)
AUDIO-R 1V
0.5ms
V-OUT E-E 0.2V 20 µs
V-OUT 10V
50
µs RF-SW 0.5V
C-PB
RF-SW 0.2V 5m
s
10V
VIDEO-Y 0.2V 20 µ s
VIDEO-C 0.2V 20 µ s
VIDEO-CVBS 0.5V 20 µ s
1-13-1
H9900WF
