FUNAI DRV-A2677 - Mechanical Parts List

20050602 1-18-1 E9700CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Comparison Chart of Models and Marks
Model Mark
DRV-A2621 A
DRV-A2677 B
DRV-A2631 C
DRV-B2737 D
Ref. No. Mark Description Part No.
A1X A FRONT ASSEMBLY E9700ED 1VM220441
A1X B FRONT ASSEMBLY E9704ED 1VM220440
A1X C FRONT ASSEMBLY E9703ED 1VM220439
A1X D FRONT ASSEMBLY E9701BD 1VM220438
A2 TOP COVER E9400UD 0VM101356C
A3 MAIN CHASSIS E9400UD 0VM101353E
A4 A,C REAR PANEL E9700ED 1VM220288
A4 B REAR PANEL E9704ED 1VM220454
A4 D REAR PANEL E9702FD 1VM220552
A10! A RATING LABEL(U) E9700ED or -----------
! A RATING LABEL(D) E9700ED -----------
A10! B RATING LABEL(U) E9704ED or -----------
! B RATING LABEL(D) E9704ED -----------
A10! C RATING LABEL(U) E9707ED or -----------
! C RATING LABEL(D) E9707ED -----------
A10! D RATING LABEL(U) E9705BD or -----------
! D RATING LABEL(D) E9705BD -----------
A14 BARCODE LABEL UNFIGURE E9704ED -----------
A14 A BARCODE LABEL E9700ED -----------
A14 B BARCODE LABEL E9704ED -----------
A14 C BARCODE LABEL E9707ED -----------
A14 D BARCODE LABEL E9705BD -----------
A34 FOOT K7010UA 0VM403657
1B1 DECK ASSEMBLY CZD014/VM25E0 N25E0FL
2B1 DECK PEDESTAL E9600UD 1VM120055
2B2 FRONT BRACKET E9400UD 0VM204534A
2B3 FRONT BRACKET R E9400UD 0VM416269A
2B4 EARTH PLATE E9400UD 0VM416272
2B9 MECHA EARTH PLATE E9600UD 1VM421129
2B10 PCB HOLDER E9700UD 1VM120056
2B11 BRACKET R E9600UD 1VM421062
2B13 JACK BRACKET E9400UD 0VM416273
2B14 CUSHION RUBBER E9400UD 0VM416664
2B19 RADIATION SHEET E9700ED 1VM320806
2B20! CAUTION LABEL(PAL) E6800ED -----------
2B31 TAPE HIMELON H9206JD 0VM413956
2B50 B GEMSTAR LABEL E6710JD -----------
2B59 JACK EARTH PLATE E9600UD 1VM320623
2B60 PLATE GROUND(21PIN) H9500ED 0VM415201
2B62 MECHA EARTH PLATE E9600UD 1VM421129
2B63 TAPE HIMELON H9500ED 0VM415504
2L011 SCREW C-TIGHT M3X5 BIND HEAD + GBCC3050
2L013 SCREW S-TIGHT M3X6 BIND HEAD+ GBMS3060
2L014 SCREW S-TIGHT M3X6 BIND HEAD+ GBMS3060
2L015 SCREW S-TIGHT M3X5 BIND HEAD+ GBMS3050
2L017 SCREW S-TIGHT M3X8 BIND HEAD+ GBMS3080
2L018 SCREW S-TIGHT M3X6 BIND HEAD+ GBMS3060
2L021 SCREW P-TIGHT M3X8 BIND HEAD+ GBCP3080
2L022 SCREW S-TIGHT M3X6 BIND HEAD+ GBMS3060
2L030 P-TIGHT SCREW 3X8 BIND + GBMP3080
2L033 SCREW S-TIGHT M3X6 BIND HEAD+ GBMS3060
2L043 P-TIGHT SCREW 3X8 BIND + GBMP3080
2L044 P-TIGHT SCREW 3X8 BIND + GBMP3080
2L045 P-TIGHT SCREW 3X8 BIND + GBMP3080
2L052 SCREW P-TIGHT M3X6 BIND HEAD+ GBMP3060
2L054 SCREW P-TIGHT M3X6 BIND HEAD+ GBMP3060
2L060 P-TIGHT SCREW 3X8 BIND + GBMP3080
2L061 SCREW P-TIGHT M3X6 BIND HEAD+ GBMP3060
2L062 SCREW B-TIGHT M3X8 BIND HEAD + GBKB3080
2L065 SCREW C-TIGHT M3X5 BIND HEAD + GBCC3050
2L071 SCREW P-TIGHT M3X10 WASHER
HEAD+
GCMP3100
2L081 SCREW S-TIGHT M3X5 BIND HEAD + GBKS3050
2L082 SCREW S-TIGHT M3X5 BIND HEAD + GBKS3050
2L100 P-TIGHT SCREW M3X34 E9400UD 1VM420034A
2L110 SCREW S-TIGHT M3X10 BIND HEAD+ GBMS3100
2L111 SCREW P-TIGHT 3X12 BIND HEAD+ GBMP3120
PACKING
S1 A GIFT BOX CARTON E9700ED 1VM320641
S1 B GIFT BOX CARTON E9704ED 1VM320725
S1 C GIFT BOX CARTON E9707ED 1VM320736
S1 D GIFT BOX CARTON E9705BD 1VM320733
S2 A,B,C SIDE PAD E9700ED 1VM120081
S2 D SIDE PAD E9701BD 1VM120075
S3 SET BAG E7708UA 0DM400731A
S10 D AC PAD HC461BD 0VM413331
S12 21P PAD E9704ED 1VM422135
ACCESSORIES
X1 A,C,D REMOTE CONTROL UNIT NB123ED NB123ED
X1 B REMOTE CONTROL UNIT NB132ED NB132ED
X2 DRY BATTERY R6P/2S or XB0M451T0001
DRY BATTERY ES-GR6M-C XB0M571GLP01
X3 RF CORD PAL 1.2M or WPZ0122LG001
RF CABLE CC1001020012010 WPZ0122LW001
X4 ACCESSORY BAG E5700UD 0VM415576
X6 21P CABLE(BYR SUPPLY) H9300ED 0VMN03276
X9 REMOCON BAG E9704ED 1VM422101
X20! A OWNERS MANUAL(ITA) E9700ED 1VMN20545
X20! C OWNERS MANUAL(GRE) R9707ED 1VMN20787
X20! D OWNERS MANUAL(ENG) E9705BD 1VMN20789
X20A! B OWNERS MANUAL(ENG) E9704ED 1VMN20560
X20B! B OWNERS MANUAL (GER) E9704ED 1VMN20886
X22 A QUICK GUIDE(ITA) E9700ED 1VMN20546
X22 C QUICK GUIDE(GRE) E9707ED 1VMN20788
X22 D QUICK GUIDE(ENG) E9705BD 1VMN20790
X22A B QUICK GUIDE(ENG) E9704ED 1VMN20793
X22B B QUICK GUIDE(GER) E9704ED 1VMN20887
X24 A SERVICE CENTER LIST HC2C0ED 0VMN03071B
X40 C WARRANTY CARD E9707ED 1VMN20828
X42 C LABEL SERIAL NO. H9500ED -----------
Ref. No. Mark Description Part No.
