20050602 1-19-14 E9700EL
JUNCTION CBA
REAR JACK CBA
METAL OXIDE FILM RES. 1W J 1.3 Ω RN01JZPZ01R3
R1020 CARBON RES. 1/6W J 1.8k Ω or RCX6JATZ0182
CARBON RES. 1/4W J 1.8k Ω RCX4JATZ0182
R1021 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R1022 CHIP RES.(1608) 1/10W J 4.7k Ω RRXAJR5Z0472
R1023 CHIP RES.(1608) 1/10W F 2.2k Ω or RRXAFR5H0222
CHIP RES.(1608) 1/10W F 2.2k Ω RRXAFR5Z0222
R1024 CHIP RES.(1608) 1/10W J 68k Ω RRXAJR5Z0683
R1025 CHIP RES. 1/10W F 5.6k Ω or RRXAFR5H0562
CHIP RES. 1/10W F 5.6k Ω RRXAFR5Z0562
R1029 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1032 CARBON RES. 1/6W J 2.2k Ω or RCX6JATZ0222
CARBON RES. 1/4W J 2.2k Ω RCX4JATZ0222
R1035 CARBON RES. 1/6W J 1k Ω or RCX6JATZ0102
CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1036 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1037 CARBON RES. 1/6W J 10k Ω or RCX6JATZ0103
CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R1038 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1039 CARBON RES. 1/6W J 470k Ω or RCX6JATZ0474
CARBON RES. 1/4W J 470k Ω RCX4JATZ0474
R1040 CARBON RES. 1/4W J 8.2 Ω RCX4JATZ08R2
R1041 CARBON RES. 1/4W J 5.6 Ω RCX4JATZ05R6
R1043 METAL OXIDE FILM RES. 1W J 2.7 Ω or RN012R7ZU001
METAL OXIDE FILM RES. 1W J 2.7 Ω or RN012R7KE009
METAL OXIDE FILM RES. 1W J 2.7 Ω RN012R7DP003
R1059 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1126 CHIP RES.(1608) 1/10W J 33k Ω RRXAJR5Z0333
MISCELLANEOUS
AC1001
!
A,B,C AC CORD PE8G2CG9G0AB05 WAE0172LW011
AC1001
!
D AC CORD PE8G2X91H0AA061 WAB0182LW016
2B18 HEAT SINK E6800ED 1VM420987
F1001! FUSE T1.6AL/250V or PAGC20BW3162
! FUSE 50T016H 1.6A/250V PAGH20BHV162
FH1001 FUSE HOLDER MSF-015 or XH01Z00LY001
FUSE HOLDER DFH-001 XH01Z00RP001
FH1002 FUSE HOLDER MSF-015 or XH01Z00LY001
FUSE HOLDER DFH-001 XH01Z00RP001
2L019 SCREW S-TIGHT M3X8 BIND HEAD+ GBMS3080
T0011! SWITCHING TRANSFORMER 5727 LTT00EPKT189
Ref. No. Mark Description Part No.
JUNCTION CBA (PSV-B)
Consists of the following:
----------
CONNECTORS
CN051A 242 SERIES CONNECTOR TUC-P19X-
B1 WHT ST or
JCTUB19TG002
CONNECTOR 19P TUC-P19X-B1 JCTUS19TG001
MISCELLANEOUS
JW1001 FLAT CABLE 10P AWG26#2651/P2.0/100 WX1E9700-003
JW1002 FLAT CABLE 9P AWG26#2651/P2.0/100 WX1E9700-004
Ref. No. Mark Description Part No.
REAR JACK CBA (PSV-C)
Consists of the following:
----------
CAPACITORS
C2003 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C2004 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C2005 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C2006 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
Ref. No. Mark Description Part No.
C2007 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C2008 CHIP CERAMIC CAP. B K 1000pF/50V CHD1JKB0B102
C2009 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100
C2010 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C2011 CHIP CERAMIC CAP. B K 1000pF/50V CHD1JKB0B102
C2012 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C2013 CHIP CERAMIC CAP. B K 1000pF/50V CHD1JKB0B102
DIODES
D2001 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2002 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2003 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2004 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2005 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2006 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2007 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2008 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2009 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2010 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
COIL
L2001 BEAD CORE ASSEMBLY E9700ED 1VSA11697
TRANSISTORS
Q2002 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F
TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815
TRANSISTOR 2SC1815-GR(TPE2) or QQS102SC1815
TRANSISTOR KTC3199(Y) or NQSY0KTC3199
TRANSISTOR KTC3199 NQS40KTC3199
Q2003 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F
TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815
TRANSISTOR 2SC1815-GR(TPE2) or QQS102SC1815
TRANSISTOR KTC3199(Y) or NQSY0KTC3199
TRANSISTOR KTC3199 NQS40KTC3199
Q2004 CHIP TRANSISTOR KTA1504GR-RTK or NQ140KTA1504
CHIP TRANSISTOR KTA1504Y-RTK NQ1Y0KTA1504
Q2005 CHIP TRANSISTOR KTA1504GR-RTK or NQ140KTA1504
CHIP TRANSISTOR KTA1504Y-RTK NQ1Y0KTA1504
RESISTORS
R2003 CARBON RES. 1/4W J 75 Ω RCX4JATZ0750
R2004 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
R2005 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R2006 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R2007 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R2008 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
Ref. No. Mark Description Part No.
