FUNAI DRV-B2737 - Electrical Parts List

20050602 1-19-1 E9700EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
Comparison Chart of Models and Marks
DVD Mechanism & DVD MAIN CBA Assy
MCV CBA
MAIN CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Model Mark
DRV-A2621 A
DRV-A2677 B
DRV-A2631 C
DRV-B2737 D
Ref. No. Mark Description Part No.
A
B
C
D
DVD Mechanism & DVD MAIN CBA Assy
DVD Mechanism & DVD MAIN CBA Assy
DVD Mechanism & DVD MAIN CBA Assy
DVD Mechanism & DVD MAIN CBA Assy
N78GABEN
N78GDBEN
N78GFBEN
N78GBBBN
Ref. No. Mark Description Part No.
A,C
B
D
MCV CBA
MCV CBA
MCV CBA
Consists of the following
1VSA11666
1VSA11746
1VSA11756
MAIN CBA (MCV-A )
POWER SW CBA (MCV-B)
FUNCTION CBA (MCV-C)
FRONT JACK CBA (MCV-D)
SENSOR CBA
----------
----------
----------
----------
1VSA11699
Ref. No. Mark Description Part No.
MAIN CBA (MCV-A )
Consists of the following:
----------
CAPACITORS
C251 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C252 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C253 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C254 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C301 CHIP CERAMIC CAP. CH J 150pF/50V or CHD1JJ3CH151
CHIP CERAMIC CAP. CG J 150pF/50V CHD1JJ3CG151
C302 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C303 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C305 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C306 CHIP CERAMIC CAP.(1608) B K 0.047µF/
50V or
CHD1JK30B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/
25V
CHD1EK30B473
C307 CHIP CERAMIC CAP.(1608) B K 0.022µF/
50V or
CHD1JK30B223
CHIP CERAMIC CAP.(1608) B K 0.022µF/
25V
CHD1EK30B223
C308 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C311 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C312 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C313 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMASSL1R0
C314 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C315 CHIP CERAMIC CAP.(1608) B K 0.047µF/
50V or
CHD1JK30B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/
25V
CHD1EK30B473
C316 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C317 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C322 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C324 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C325 CHIP CERAMIC CAP. B K 8200pF/50V CHD1JK30B822
C326 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C327 ELECTROLYTIC CAP. 220µF/6.3V M H7 CE0KMAVSL221
C328 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C329 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C331 ELECTROLYTIC CAP. 220µF/6.3V M H7 CE0KMAVSL221
C333 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C334 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C335 ELECTROLYTIC CAP. 100µF/6.3V H7 CE0KMAVSL101
C336 CHIP CERAMIC CAP. CH J 220pF/50V or CHD1JJ3CH221
CHIP CERAMIC CAP. CG J 220pF/50V CHD1JJ3CG221
C337 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C339 CHIP CERAMIC CAP. CH J 120pF/50V or CHD1JJ3CH121
CHIP CERAMIC CAP. CG J 120pF/50V CHD1JJ3CG121
C340 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C341 CHIP CERAMIC CAP.(1608) CH D 10pF/
50V or
CHD1JD3CH100
