MERIT SERIES PowER CondITIonERS • EnGLISH
7
SPECIFICATIONS
Maximum Output Current:
15 amps
Line Cords:
Captive 6 foot cord, 3x14 AWG
Lamps (If present):
Two 120V incandescent bulbs, 4 watts each
Operating Voltage:
120VAC 60HZ
Spike Protection Modes:
Line to Neutral
Energy Dissipation:
150 joules
Peak Impulse Current:
12,000 amps
Maximum Continuous Operating Voltage:
130 VAC RMS
Noise Attenuation (Transverse Mode):
M-8x
2
: Greater than 23db, 200Khz to 10MHz
M-8Lx: Greater than 26db, 200Khz to 10MHz
M-8Dx: Greater than 26db, 200Khz to 10MHz
Dimensions:
M-8x
2
: 1.75” H x 19” W x 3.75” D
M-8Lx/M-8Dx: 1.75” H x 19” W x 7.5” D
Weight:
M-8x
2
: 4 lbs. (2 Kg.)
M-8Lx: 6 lbs. (2.7 Kg.)
M-8Dx: 6 lbs. (2.7 Kg.)
Construction:
Steel Chassis, Black Painted
