Stereo Information
Specifications
Weight 350 g (12.4 oz.)
Water rating
IEC 60529 IPX6 and IPX7 (front of stereo only, when properly installed)
1
IEC 60529 IPX2 (rear of stereo)
Operating temperature range From 0 to 50°C (from 32 to 122°F)
Storage temperature range From -20 to 70°C (from -4 to 158°F)
Input voltage From 10.8 to 16 Vdc
Current (max.) 15 A
Current (muted) Less than 400 mA
Current (off) Less than 100 mA
Fuse 15 A mini-blade type
NMEA 2000 LEN @ 9 Vdc 1 (50 mA)
Bluetooth
®
wireless range Up to 10 m (30 ft.)
ANT
®
wireless range Up to 3 m (10 ft.)
Wireless frequencies/protocols
Bluetooth 2.4 GHz @ 12 dBm nominal
ANT 2.4 GHz @ 7 dBm nominal
Compass-safe distance 15 cm (5.9 in.)
On-board, Class D amplifier
Output music power per channel 4 x 50 W max. 4 Ohm
Total output peak power 200 W max.
Output power per channel 4 x 26 W RMS at 14.4 Vdc input, 4 Ohm, 10% THD
2
Line output level (max.) 5.5 V (peak to peak)
Aux input level (typical) 1 V RMS
Tuner frequencies
Tuner Europe and Australasia USA Japan
FM radio frequency range 87.5 to 108 MHz 87.5 to 107.9 MHz 76 to 95 MHz
FM frequency step 50 kHz 200 kHz 50 kHz
AM radio frequency range 522 to 1620 kHz 530 to 1710 kHz 522 to 1620 kHz
AM frequency step 9 kHz 10 kHz 9 kHz
1
When properly installed, the front of the stereo withstands incidental exposure to water of up to 1 m for up to 30 min, and is protected against powerful jets
of water. For more information, go to www.garmin.com/waterrating.
2
The stereo may limit the output power to prevent the amplifier from overheating, and to maintain the audio dynamics.
12 MS-RA210 Installation Instructions
