Product description
1
3
4
2
5
6
7
1 Control panel
2 Door
3 Fluff filter
4 Rating plate
5 Adjustable feet
6 Sideways vent outlets / back vent outlet
7 Ring nut
Control panel
1 2 4 53
1
Programme knob and - "O" (OFF) switch
2 Function buttons (from left to right:)
DELICAT (DELICATE) , TEXTILE
3 Programme phase lights (from up to
down:)
- SECHAGE (DRYING) light
4
