Futech DISTY40 - Device Overview and Components; Front Panel Controls; Display Indicators and Symbols

DISTY40 / DISTY80
3
1
3
4
2
6
7
5
8
9
11
10
19
15
22
23
24
25
26
27
28
21
20
12
13
14
16
17
18
MANUAL
1. Display
2. On / DIST (on / measuring)-button
3. Timer
4. Tilt-functions
5. Function-button
6. Plus-function
7. Minus-function
8. Memorybutton
9. Referencepoint
10. Beep / Units
11. Delete / Off - button
12. Laser active
13. Referencepoint in front
14. Referencepoint at the back
15. Reference point positioning bracket
16. Max. and Min.-measurement
17. Surface / Volume
18. Indirect measurement
- Single pythagoras
- Double pythagoras
- Double pynth. (half heigt)
- Tilt-function , of
19. Digital waterlevel / record number
20. Memorysymbol
21. Error-symbol
22. Timer
23. Single / continue measurement
24. Battery
25. Intermediate line 1
26. Intermediate line 2
27. Intermediate line 3
28. Summary line
