FDC_C-Series_Quick_Operation_User_Manual_UMQOC621A.doc Page 7 of 20
Modbus
Register
Address
Parameter
Notation
Parameter Description Range
41 A2FN Alarm 2 function for alarm 2 output
NoNE: No alarm function
dtMR: Dwell timer action
dE.HI: Deviation high alarm
dE.Lo: Deviation low alarm
db.HI: Deviation band out of band alarm
db.Lo: Deviation band in band alarm
PV.HI: Process value high alarm
PV.Lo: Process value low alarm
H.bK: Heater break alarm
H.St: Heater short alarm
E1.C.o: Event Input 1 Control Alarm Output
E2.C.o: Event Input 2 Control Alarm Output
42 A2MD Alarm 2 operation mode
NoRM: Normal alarm action
LtCH: Latching alarm action
HoLd: Hold alarm action
Lt.Ho: Latching & Hold action
SP.Ho: Set point holding alarm
43 A2HY Hysteresis control of alarm 2 Low: 0.1°C High: 50.0°C(90.0°F)
44 A2FT Alarm 2 failure transfer mode
OFF: Alarm output OFF if sensor fails
ON: Alarm output ON if sensor fails
45 A2SP Alarm 2 set point Low: -19999 High: 45536
46 A2DV Alarm 2 deviation value Low: -19999 High: 45536
47 A3OT Alarm 3 output
A
LM: Alarm 3 output
RALM: Reverse Alarm3 Output
48 A3FN Alarm 3 function for alarm 3 output
NoNE: No alarm function
dtMR: Dwell timer action
dE.HI: Deviation high alarm
dE.Lo: Deviation low alarm
db.HI: Deviation band out of band alarm
db.Lo: Deviation band in band alarm
PV.HI: Process value high alarm
PV.Lo: Process value low alarm
H.bK: Heater break alarm
H.St: Heater short alarm
E1.C.o: Event Input 1 Control Alarm Output
E2.C.o: Event Input 2 Control Alarm Output
49 A3MD Alarm 3 operation mode
NoRM: Normal alarm action
LtCH: Latching alarm action
HoLd: Hold alarm action
Lt.Ho: Latching & Hold action
SP.Ho: Set point holding alarm
50 A3HY Hysteresis control of alarm 3 Low: 0.1°C High: 50.0°C(90.0°F)
51 A3FT Alarm 3 failure transfer mode
OFF: Alarm output OFF if sensor fails
ON: Alarm output ON if sensor fails
52 A3SP Alarm 3 set point Low: -19999 High: 45536
53 A3DV Alarm 3 deviation value Low: -19999 High: 45536
54 A4OT Alarm 4 output
A
LM: Alarm 4 output
RALM: Reverse Alarm 4 Output
55 A4FN Alarm 4 function for alarm output
NoN
E
: No alarm function
dtMR: Dwell timer action
dE.HI: Deviation high alarm
dE.Lo: Deviation low alarm
db.HI: Deviation band out of band alarm
db.Lo: Deviation band in band alarm
PV.HI: Process value high alarm
PV.Lo: Process value low alarm
H.bK: Heater break alarm
H.St: Heater short alarm
