11
29.3.1998
List of materials for
PCB SC-780 V.1
Document No.:
3/3
POS. ARTICAL TYPE DESCRIPTION Q'TY
SPARE PARTS
No.
98 X21 HC-49/U-S CRYSTAL 20MHz 1
99 RE1 40.61 12V/DC RELE "FINDER"-16A/250V 1
100 CON1 PSL10 CONNECTOR 1
101 CON2
PAW2.54 CONNECTOR 3102 CON3
103 CON4
104 CON5
PSL20 CONNECTOR 3
105 CON6
106 CON7
107 SV1
ARK500/2 TERMINAL BOARD 6
108 SV2
109 SV2
110 SV3
111 SV4
112 SV5
113 J1 AC3FDP CONNECTOR 1
114 J2 AC3MDP CONNECTOR 1
115 F10 T2A FUSE 1
116 F11
T6.3A FUSE 2
117 F12
118 DP02 P FUSE HOLDER 3
119 PCB SC 780 V1 PRINTED CIRCUIT BOARD 1
29.3.1998
List of programs
for SC - 780
Document No.:
1/1
POS. ARTICAL TYPE DESCRIPTION Q'TY
SPARE PARTS
No.
PCB1 - SC 780 V.1
1IC1
PIC 16C57 HS/P
Microcontroller
SC780 V1.1 / IC1 1
2IC2
PIC 16C57 HS/P
Microcontroller
SC780 V1.1 / IC2 1
3IC3
PIC 16C57 HS/P
Microcontroller
SC780 V1.1 / IC3 1
4IC4
PIC 16C57 HS/P
Microcontroller
SC780 V1.1 / IC4 1
PCB2 - Num. Disp SMD V2
1IC1
PIC 17C43
Microcontroller
SC 780 DISP V1.2 / IC1 1
2 IC2 24C08 EEPROM SC 780/E V1.1 / IC2 1
