List of materials for
SC - 780
Document No.:
1/2
POS. ARTICAL TYPE DESCRIPTION Q'TY
SPARE PARTS
No.
1 Q1 863109 1-56/1.5 NON-DETACHABLE CORD "FLEXO" 1
2 SW1 VMN-10,10A SWITCH 1
3
F2
T5A FUSE 1
4 PTF55 FUSE HOLDER 1
5 F3 US-602SXQR THERMAL FUSE 90°C 1
6 TL1 AL575FV BALLAST 1
7 ST1 1579K STARTER 1
8 C1 70µF/250V AC CAPACITOR 1
9 TR1 980604 TRANSFORMER 1
10 DT1 HMI 575 METAL HALIDE LAMP 1
11 M1
17PM-TO11-04V STEPPING MOTOR 7
12 M2
13 M3
14 M4
15 M5
16 M6
17 M7
18 M8 17PM-TO11-03V STEPPING MOTOR 1
19 M9
17PM-TO11-04V STEPPING MOTOR 4
20 M10
21 M11
22 M12
23 M9 KD 1212PME-6A FAN 12V/DC 1
24 PCB1 SC 780 V.1 FILL PRINTED CIRCUIT BOARD 1
25 PCB2 DISP SMD V2 FILL PRINTED CIRCUIT BOARD 1
PCB 3
26 IT1 L-932P3BT INFRARED-TRANSISTOR 1
27 Rt1 TER640 15K TERMISTOR 1
28 CNG2 PRINTED CIRCUIT BOARD 1
PCB 4
29
J1
PSL20 CONECTOR 1
30 PCB-2 PRINTED CIRCUIT BOARD 1
PCB 5
31
J2
PSL20 CONECTOR 1
32 PCB-2 PRINTED CIRCUIT BOARD 1
PCB 6
33 J3 PSL20 CONNECTOR 1
34 PCB-2 PRINTED CIRCUIT BOARD 1
