Future light SC-780 - Page 6

6
29.3.1998
List of materials for
SC - 780
Document No.:
2/2
POS. ARTICAL TYPE DESCRIPTION Q'TY
SPARE PARTS
No.
PCB 7
35
S1
HAL506UA-A MAGNETIC SCANNER 1
36 MAG1 PRINTED CIRCUIT BOARD 1
PCB 8
37
S2
HAL506UA-A MAGNETIC SCANNER 1
38 MAG1 PRINTED CIRCUIT BOARD 1
PCB 9
39
S3
HAL506UA-A MAGNETIC SCANNER 1
40 MAG1 PRINTED CIRCUIT BOARD 1
PCB 10
41
S4
HAL506UA-A MAGNETIC SCANNER 1
42 MAG1 PRINTED CIRCUIT BOARD 1
PCB 11
43
S5
HAL506UA-A MAGNETIC SCANNER 1
44 MAG1 PRINTED CIRCUIT BOARD 1
CONNECTING CABLE : W10/18 V1.0
45
Jx
PFL10 CONNECTOR 2
46 AWG28-10 WIRE 0.18m
CONNECTING CABLE : W20/40 V1.0
47
Jx
PFL20 CONNECTOR 2
48 AWG 28-20 WIRE 0.4m
CONNECTING CABLE : W20/45 V1.0
49
Jx
PFL20 CONNECTOR 2
50 AWG28-20 WIRE 0.45m
51 CSA 1black WIRE 3.1m
52 CSA 1light blue WIRE 1.9m
53
CSA
1green/yellow
WIRE 1.9m
54 CSA1red WIRE 3.2m
55 CSA0.5white WIRE 1.6m
56 NTN5A CABLE EYE 3
57 141564 FLAT CONNECTOR 3
58 146094 FLAT CONNECTOR 2
59 041.0-5x0.5 INSULATING TUBE 0.05m
60 041.0-3x0.5 INSULATING TUBE 0.04m
61 068.0-4x0.5 INSULATING TUBE 0.05m
62 068.0-5x0.5 INSULATING TUBE 0.25m
63 068.0-5x2 INSULATING TUBE 0.35m
