Fig. 3
1.sealing ring
2.connection
3.fixing screw
3)Connect the spray unit to the machine as shown in Fig. 4
2. Assembly of the spray nozzle
Fig. 5
2. Flexible hose
2. Spray pipe
3. Handle/gas handle
4. Pipe Elbow
5. Spray attachment chemical
6. Pipe clamps
7. Hose
1
3
2
6
4
5
7
