FXA DRM24E-D225 - Scope of Delivery

7
2.Layout:
1.Seat
9. Catch basket
17.Oull cable starter
2. Steering wheel
10. Rear wheels
18.Fuel tank cover
3.Brake pedal
11.Rear chute
19.Air filter
4.Front tyres
12.Ignition lock
20.Oil tank cover
5.battery compartment
13.Forward/Reverse gear
21.Exhause pipe
6.Water pipe connection
14.Throttle
22.Spark plug
7.Cutting height setting
15.Seat Position adjustment
23.Head light
8. Cutter clutch
16.Locking brake
24. Head light switch
3.Scope of delivery
Open the packaging and remove the device carefully.
Remove the packaging material as well as the packaging and transport bracing (if
available).
Check that the delivery is complete.
Check the device and its spare parts for possible damage caused by transportation. In
the event of complaints, you must contact the distributor without delay. Claims at a
later stage will not be accepted.
If possible, store the packaging until the warranty period has expired.
