Before handling the device, make yourself familiar with it by reading the operating
instructions.
For accessories, consumables and spare parts, only use original parts. Spare parts
are available from your stockiest.
Include our item number, the device model and year of manufacture in your order
No
Part name
Qty
No
Part name
Qty
1
Steering column assembly
1
2.3
Bolt
2
1.1.
Steering wheel cover
1
3
Decorative tube
1
1.2
Flange nut
1
4
Funnel
2
1.3
Flat washer
1
5
20V Li-ion battery
1
1.4
Steering wheel
1
6
Charger
1
1.5
Steering wheel hub
1
7
Start keys
1
1.6
Flange Washer
2
8
Wrench
2
1.7
Bushing
1
9
Grass Catcher
1
1.8
Steering column
1
10
Side Discharge
1
2
Seat assembly
1
11
Manual
1
2.1
Seat
1
12
Spark Plug Wrench
1
2.2
Nut
2
