FXA GL51YL-B - Wheels Assembly; Side Discharge Cover Assembly; Technical Data

- 8 -
Wheels Assembly
- Put four wheels into corresponding wheel axle and tighten nuts, then fasten wheel covers on wheels.
Side Discharge Cover Assembly
- Lift the side discharge guard, install the side discharge cover.
Only Mulching: Please remove the side discharge cover.
3. TECHNICAL DATA
Model
501741207 / GL51YL-B
Engine type
Y139V
Engine Displacement
139 cm
3
Nominal Power
2.6 kW
Blade Width
508 mm
Rated Speed
2800/min
Gasoline Tank Capacity
1.0 L
Net Weight
26.50 kg
Height adjustment
25-75 mm, 6 adjustment
