FXA PLUS SMC46BRS - Page 21

- 21 -
10. PART LIST
Pos.
No.
Part No.
Description
Specification
Remark
Qty.
A
Part A
A-1
G3376000001
Clutch Lever
Q235
Ø7.8mm
1
A-2
G3353000005
Brake Lever
Q235
Ø7.5mm, P109C
1
A-3
G3XW0000000
Limiting Stopper
PA66
1
A-4
G3320000000
Foam Pipe
NBR
20x510x3mm
1
A-5
G333F200063
Upper Handle Assembly
Q235
Ø22/t=1.35
1
A-6
B2011B00000
Nut
M6
2
A-7
G339X300000
Cable Fixing Clamp
PA66+GAF
1
A-8
G639XX50000
Brake Cable
G639XX50000
1
A-9
G339XYA0000
Clutch Cable
G339XYA0000
1
A-10
B1066W06032
Bolt
M6x32
1
A-11
G33B4000063
Lower Handle
Q235
Ø22/t=1.35
1
A-12
B1088W08050
Bolt
M8x50
4
A-13
B5019W00000
Flat Washer
Ø8.5xØ16x1.5mm
4
A-14
G33C1100014
Knob
PP
4
A-15
B2020W00000
Nut
M8
4
A-16
G33K0000000
Rope Guide
Q235
Ø6mm
1
A-17
G33H0000000
Cable Support
PP
2
A-18
B1087W08032
Bolt
M8x35
2
A-19
B2009W00000
Nut
M8
2
A-20
G33J0000000
Handle Plug
PP
2
B
Part B
B-1
B1065B06030
Bolt
M6x30
2
B-2
G33E1000014
Handle Panel
ABS
P109C
1
B-3
B2011B00000
Nut
Q235
M6
2
C
Part C
C-1
BS450EOHV00
Engine
80
BS450E(OHV)
1
C-2
B3001B00000
Screw
3/8-16x1ST
3
C-3
BE001W00000
Flat Key
45
1
C-4
G34AWY00000
Blade Adapter
1
C-5
G22K0000000
Screw Cap
PVC
2
C-6
G5230000000
Belt Cover
PP
1
C-7
B3022W00000
Screw
ST4.8x12-F-H
2
C-8
G323G000000
Cover plate 1
PP
1
C-9
G323H000000
Cover plate 2
PP
1
C-10
B3034W00000
Screw
ST4.2x15-C
2
C-11
G3510000000
18" Blade
40MnB
t=3.0
1
C-12
G3520000000
Blade Washer
65Mn
t=3.0
1
C-13
B1001B00032
Blade Bolt
20Cr
3/8-24UNF-2Bx32
1
D
Part D
