FXA PLUS SMC46BRS - Page 22

- 22 -
D-1
B1036W08015
Bolt
M8x15
4
D-2
G54BD000000
Height Adjustment Plate
Q235
1
D-3
G32B0000000
Right Bracket
Q235
t=3.0
1
D-4
B2009W00000
Nut
M8
4
D-5
G3217Y00063
Deck
G46SL-F
ST1.35
1
D-6
G56N0000000
Mulching Plug
ABS
1
D-7
G52E0000000
Cable Sleeve
PVC
1
D-8
BD001B00000
Seal Ring
NBR
Ø11xØ2.5
1
D-9
G32D0000100
Washing Linker
PP
G46
1
D-10
B2025B00000
Plastic Nut
PP
M12x1.5
1
D-11
G32C0000000
Left Bracket
Q235
t=3.0
1
D-12
G32J0000000
Rear Cover Support
PP
2
D-13
B1059W06014
Bolt
M6x14
3
D-14
G32A0000000
Rear Cover Pedestal
PP
1
D-15
B2008W00000
Nut
M6
3
D-16
G32K0000000
Plug
PP
G46
2
D-17
G36B0000010
Rear Cover
PP
1
D-18
G36J0000000
Rear Cover Spring
Ø2
1
D-19
G36E0000000
Rear Cover Shaft
Q235
Ø6
1
D-20
G3240000010
Front Plastic Face
ABS
1
D-21
B3023W00000
Screw
ST4.8x15-F-H
4
D-22
G52F0000000
Washer L
PP
1
D-23
G52G0000000
Washer R
PP
1
D-24
B2007W00000
Nut
M5
2
D-25
G3250000000
Side Discharge Bracket
Q235
t=2.0
1
D-26
B1052W05010
Bolt
M5x10
2
D-27
G5260000000
Side Discharge Cover Shaft
Q235
Ø6
1
D-28
G3271000000
Side Discharge Cover
Spring
Ø2
1
D-29
G5280000000
Side Discharge Cover
PP
1
D-30
G5290000000
Side-Discharge Guiding
Board
PP
1
E
Part E
E-1
G3420000014
Height Adjustment Handle
PP
P109C
1
E-2
G5490000300
Rear Wheel Shaft Assembly
1
E-3
G34AC000000
Inner Wheel Cover
PP
2
E-4
B6009B00000
Spring Washer
Ø13xØ19x0.5x2
4
E-5
B1057W06010
Bolt
M6x10
3
E-6
B0014W00000
Ball Bearing
R8-2RS
4
E-7
G34L0000000
10" Wheel
2
E-8
B5031W00000
Flat Washer
Ø13.2xØ24x3
2
E-9
B2017W00000
Nut
M8
4
E-10
G34V0000014
10" Outer Wheel Cover
PP
P109C
2
E-11
BB004W00000
Split Pin
D2x20
1
E-12
BA00FB00000
Belt Li700
Li650
1
