EEG6500 Enhanced Electronic Governor 05.09.18 PIB 5010 F
EEG6500 Technical Assistance Worksheet
Please provide the following information so we assist you with timely, technical recommendations:
Date:
Company Name:
Contact Info:
E-Mail Address:
Phone Number:
Reported Problem:
Engine Make, Model & Application:
Controller Model and Serial Number:
Actuator Model and Serial Number:
EEG6500 GOVERNOR SETTINGS
Parameter Factory Settings Customer Settings
Gain 50 (Rated) 10 (Idle)
Stability 50
Deadtime HI
Speed 1500RPM
Idle 900 RPM
Fuel Limit % 100
Start Fuel % 100
Droop % 5.0
Fuel Ramp % 10
Speed Ramp 300 RPM/sec
V. Speed 1800 RPM (VSPD) 0 Hz (Trim)
Overspeed 2000 RPM
# of Teeth 120
Crank 400 RPM
ADVANCED SETTINGS
Parameter Factory Settings Customer Settings
AUX Off
VSPD Off
LFG Off
LEAD Off
NLCU 0.5
FLCU 4.0
JADR 0
FLTL ------
DAT L ------
FLTL ------
ELECTRICAL CHECKS
F(+) & E (-) 12 or 24 Volts DC
C & D 1.0 VAC RMS Min. at Cranking
F (+) & A (-) 1.0 to 2.0 VDC While Cranking
ADVANCED MENU PARAMETERS (READ ONLY)
Parameter Factory Settings
Software Revision
Number
SREV ------

GAC EEG6500 Specifications

General

Brand	GAC
Model	EEG6500
Category	Controller
Language	English
