IMPORTANT

BEFORE STARTING THE INSTALLATION OF THE ELECTRASTREAM CHECK ALL COMPONENTS HAVE

BEEN DELIVERED AND ARE IN SATISFACTORY CONDITION - Refer to 1-3 .

HEALHEAL

HEAL

TH & SAFETYTH & SAFETY

TH & SAFETY

❍ Indirect cylinder coils may be fractured, consult GAH (HEATING PRODUCTS).

❍ *Check to make sure there is air charge pressure in the accumulator. If air is not

present, suspect faulty accumulator. Consult GAH (HEATING PRODUCTS).

Make the system safeMake the system safe

Make the system safe

● Turn off the system at the isolator or consumer unit.

● Turn on a hot tap until it runs cold to reduce the pressure and temperature.

● Turn on the radiators - ensuring all thermostatic valves are open.

● Contact the installer.

Investigate possible causesInvestigate possible causes

Investigate possible causes

❍ Check there are no restrictions in the hot water pipework.

❍ Check for loss of pressure in the hot water expansion vessel.

❍ Check for loss of pressure in the heating expansion vessel.

❍ Check pressure reducing valve (on combination valve, see 4-3.3).

❍ Check for back feed of high mains pressure from expansion valve.

❍ The heating system should not be run with all the radiators turned off unless there is

a bypass valve in the system, see figs. 1-2a and 1-2b.

❍ Check for air in the heating system.

❍ Check that the cylinder temperature sensor has not been dislodged from the phial in

the cylinder.

❍ With the heating elements and heating pump turned OFF, check for error messages

on the Electrastream Control Unit.

❍ With the heating elements and heating pump turned OFF, check the target

temperature of the Electrastream Control Unit (see step 8, fig. 2-2b).

❍ With the heating elements and heating pump turned OFF, check for error messages

on the Electrastream Control Unit.

AULAUL

AUL

T FINDING 7T FINDING 7

T FINDING 7

In the event of water/steam

being seen at the discharge

pipe or tundish

WARNING

Scalding water and steam can be

blown out of the tundish and

discharge pipe

WARNING

Please ensure that no water has

come into contact with any

electrical device before the

electrical supply is turned back on.

Hot water discoloured

* Electrastream Plus only
