4
• Relative humidity of an air at the temperature of +20° С should be no more
than 75%;
• Non-explosive environment; the environment should not contain aggressive
gases and steams destroying metal and isolation; the environment should
not contain an industrial dust in quantities adversely affecting the boiler
operation.
There are no combustible materials in the construction of the boilers, therefore our
boilers are fireproof.
Boilers meet the requirements of the Technical Specifications (TS) No. 3468-001-
17289826-02.
Order designations: “Galan – XXX-№” electrode boiler (“XXX” is a name of the
boiler).
Annotation: “№” is a power of the boiler in accordance with the Table 1.
Example: “Galan – Ochag-6” electrode boiler.
All of the “Ochag”, “Geyser”, and “Vulkan” electrode boilers described in the Table
1 are certified.
Number of the certificate of conformity: РОСС RU.ME71.H00072 dated 29.03.05.
The Certification authority: The Electrical Products Certification Authority of the
Independent Noncommercial Organization on Certification of the Electrical
Products, 109052, Moscow, ul. Nizhegorodskaya, 29.
Voluntary certification.
Technical characteristics of the boilers produced by the “Firma “Galan” Joint-Stock
Company
Table 1
Name of the boiler
Boiler characteristics
Ochag-2
Ochag-3
Ochag-5
Ochag-6
Geyser-9
Geyser-15
Vulkan-25
1. Size of the heated
space (cubic meters)
80
120
175
200
340
550
850
2. Nominal power
consumption (kW)
2
3
5
6
9
15
25
3. Nominal voltage (V)
220
220
220
220
380
380
380
4. Approximate energy
consumption (kW/h)
(with normal
thermal protection
of premises)
0,5
0,75
1,25
1,5
2,5
4
6,6
5. Max. current
strength of the
boiler on each phase
(A) (current
frequency – 50 Hz)
9,1
13,7
22,7
27,3
13,7
22,7
37,5
6. Nominal current
strength of the
automatics (A),
electromechanical
model
10
16
25
32
3x16
3x25
3x40
7. Cross
section of
current-
carrying
copper
connection
cable core
(sq. mm)
220 V
4
4
4
6
380 V
4
4
6
8. Max. (operating)
temperature of the
heat-transfer agent
on the outlet of the
boiler (ºC)
90
9. Recommended
volume of the heat-
transfer agent in the
heating system
20-40
25-50
30-60
35-70
50-100
100-200
150-300
