Galanz DC-80S1E - Technical Data

2
 1. Technical Data
1.1 data table
Overall size
595*630*845mm
Drum Capability
8KG
Weight
45KG
Power Connection
Voltage：230V Frequency：50Hz
Maximum Power
DC-80S1E（2500W） DC-80S1U（2700W）
1.2 Electrical Component
1.21 Heating Tube
1.22 Rated Voltage：230V
1.23 rated power：800W/1400W ,deviation range: +5% -10%
1.24 temperature controller： TOD 36FXE L170C
1.25 temperature sensor：B25/75=3965K ±1%
1.3 Main Motor
 1.31 Type： Single phase asynchronous motor
 1.32 Rated Voltage：230V
 1.33 Frequency：50Hz
 1.34 Power Consumption：140We
 1.35 Class of insulation: F
 1.36 Condensation pump
 1.37 voltage：220-240V
 6.8 Frequency：50Hz
 6.9 Resistance：750+/-750hm
 6.10 Rate：3000/min
 6.11 Class insulation: F
7. Micro switch
7.1. Technical parameter：16（3）A 250V T125
8. Capacitance
8.1 Technical parameter
：DC-80S1E(10μF±5% 450V) DC-80S1U(9μF±5% 450V)
