The Galaxy Audio S5N-8 and ST1.5
are ferro fluid cooled drivers.
SPECIFICATIONS
170 Watts @ 4 Ohms < 0.5% THD @ 4 Ohms
4 ohms 80 Hz - 18 kHz Three Band Center Detent LOW: +/-12 dB @ 200 Hz MID: +/-12 dB @ 2 kHz HIGH: +/-12 dB @ 10 kHz Two 1/4" Balanced/Unbalanced Two XLR 24V Phantom PWR
One 1/8" Stereo Line In Two XLR Thru Outputs
One 1/4" Preamp Output DOMESTIC: 120Vac~ 60Hz
EXPORT: 230Vac~ 50Hz
6.5" Neolite Woofer, 1.5" Neolite Dome Tweeter Fire Retardant Styrene 7.75"x 11.75"x 6.75"
(197mm x 298mm x 171mm) 6.4 lbs. (2.9 kg)
25 Watts @ 4 Ohms < 0.5% THD @ 4 Ohms
4 ohms 150 Hz - 17 kHz Two Band Center Detent LOW: +/-12 dB @ 200 Hz
HIGH: +/-12 dB @ 10 kHz
One 1/4" Balanced/Unbalanced One XLR 24V Phantom PWR
One 1/8" Stereo Line In Included Power Supply Input 100-240 VAC, Output 18 VDC, 1.75 A
3" Driver, 4 Ohms, Fire Retardant Styrene 5" x 4.25" x 4.5" (127mm x 108mm x 114.3mm) 1.75 lbs. (.793 kg)
Power Output Distortion Minimum Load Frequency Response Equalization Input Connections Output Connections Power Requirements Speaker Compliment Enclosure Dimensions Net Weight
PA6S NSPA
