6.4 CURTAIN REPLACEMENT
Before any operation check wear on the curtain and on the attaching
devices. Replace worn curtain.
Use exclusively curtains supplied by GALFRÈ.
Mod. FR/G 170 – FR/G 190 – FR/G 210
In order to remove the damaged curtain, loosen the clamping screws on all
sides, as shown in the picture.
Place the curtain on the borders of the cutter unit and secure it with screws,
washers and nuts.
Mod. FR/G 130
In order to remove the damaged curtain, loosen the belts connected to the
frame of the cutter unit
Fold back the curtain and secure it with belts.
Operator’s and Maintenance Manual – Rotary Drum Mowers and Conditioners
50
