Gallagher 3E3958 110V Energizer User Manual
Step 3. Connect the fence
Connect the energizer’s red (FENCE) terminal to the fence using double
insulated cable. Remove 2” of plas c coa ng from one end of the cable.
Bend the end of the wire to form a loop. Unscrew the red (FENCE)
terminal and insert the loop of wire between the washers. Screw the
terminal closed, ensuring the wire is fi rmly clamped. A ach the other end
of the cable to the fence using a joint clamp.
Red
Green
To fence
To ground
