5-Step Installa on Guide
4STEP INSTALLATION GUIDE
Step 1. Mount the Energizer
The energizer is easy to install. Mount the energizer on a wall,
under cover, out of reach of children, adjacent to a power outlet.
Install where there is no risk of the energizer incurring fi re or
mechanical damage.
1. Using the the template on the centre page as a drilling
guide, drill 2 x 4mm (5/32”) holes (A & B).
2. Fix the screws provided into the wall leaving the head
of the screw about 3mm (
1
/
8
”) out from the wall.
3. Place the energizer over and slide down onto the
moun ng screws.
2.
1.
