Gallagher 3E1802 Small Mains Energizer User Manual
11
5-Step Installa on Guide
Step 4. Connect the fence
Connect the energizer’s red (FENCE) terminal to the fence using double insulated
cable. Remove 5cm (2”) of plas c coa ng from one end of the cable. Bend the end
of the wire to form a loop. Unscrew the red (FENCE) terminal and insert the loop of
wire between the washers. Screw the terminal closed, ensuring the wire is fi rmly
clamped. A ach the other end of the cable to the fence using a joint clamp.
Step 5. Plug the energizer into a power outlet
Check that the light on the front of the energizer is fl ashing.
Red
Green
To fence
To earth
Light
