English
Gallagher 3E1802 Small Mains Energizer User Manual
12
Op ons for wire & post spacings
OPTIONS FOR WIRE AND POST SPACINGS
These gures are guidelines only for at country condi ons.
Note:
Symbol indicates a live, pulse-carrying wire
Symbol indicates an earth wire
For wire and post spacings in dry areas with poor earthing condi ons, see your
Gallagher dealer.
