9 OVERVIEW OF THE UNIT
9.1 Disassembling the unit
WARNING
Switch off all power — i.e. unit power supply and backup heater and domestic hot water tank power supply (if
applicable) — before removing door 1 and door 2.
Parts inside the unit may be hot.
Door 1
To access to the compressor and
electrical parts.
Door 1
Door 2
To access to the hydraulic
compartment and electrical parts.
To access to the compressor and
electrical parts and hydraulic
compartment
4/6kW
8/10/12/14/16kW
1 12
10.5.15
