Capacity of
backup
heater
3kW(1-phase)
Backup heater (optional)
3kW(1-phase) or 9kW(3-phase)
Unit
1-phase 3-phase
4
6
8
1612 14
The standard unit is without backup heater. Backup heater can be integrated in the unit for customized models(4~16kW).
16
12
14
8/10/12/14/16 kW4/6 kW
8/10/12/14/16 kW
4/6 kW
Please remove the hollow
plate after installation.
Internal layout:12~16kW(3-phase) for example
Electric Control System
Terminal Block
Hydraulic System
Refrigerant System
The picture and function described in this manual contain the backup heater components.
Pictures in this manual are for reference only, please refer to the actual product.
NOTE
10
12/14/16 kW
Remove the
transportation support
Installation and operation manual - air-water heat pump Prima © All rights reserved - Galmet Sp. z o.o. Sp. K.90
