Installation direction: door open facing outward (PK300DC)
L
K
L=620+5L=620+5
K＜620+340620+340
A
B
Note:Note: SafetySafety stopperstopper mustmust bebe
installed,installed, isis proviedprovied byby installerinstaller
Note:Note: LimitLimit stopperstopper mustmust bebe installedinstalled
Figure 10
100 110 120 130 140 150 160 170 180 190 200
100
110
120
130
140
150
160
170
180
190
200
Max 90°
Max 100°
Max 110°
Max 120°
mmmm
B
A
Figure 11
Note: Value B must be close to or equal to the value A to obtain the best mechanical
advantage.
Installation direction: door open facing inward (PK350DC)
