Game Winner DOUBLE UP - Install Seating & Standing Platform Connect Bars and Accessory Hooks; Install Arm Rest

Assembly Instructions
Step 5:
18
Figure 5
Install Seating & Standing
Platform Connect Bars and Accessory Hooks
Locate two Seating & Standing
Platform Connect Bars (#10)
and two Accessory Hooks
(#20).
A: Install the Seating &
Standing Platform Connect
Bars (#10) onto the Seating &
Standing Platform (#1,#2)
using six (6) M8x55 Bolts,
tweleve (12) Steel Washers
and six (6) Locknuts as shown
in Figure 5.
B: Install the Accessory
Hooks (#20) onto the Seating
& Standing Platform Connect
Bars (#10) using two (2)
M6x35 Bolts, four (4) Steel
Washers and two (2) Locknuts
as shown in Figure 5.
Step 6:
Locate two Arm Rests (#3).
Install the Arm Rests (#3)
onto the Seating Platform (#1)
using four (4) M8x55 Bolts,
eight (8) Steel Washers and
four (4) Locknuts as shown in
Figure 6.
Figure 6
Install Arm Rest
