Reference SL Articulator and Face Bow Systems
- 43 -
Attach and fix the adjustment blocks.
Attention:
Inserting direction as shown in adjoining picture!
Lock the upper and the lower part of the articu-
lator in centric zero position with the calibration
key.
Attention:
Clean the grooves of both the calibration key
and the articulator in advance. The key must
be locked tightly! Remove the incisal table and
incisal pin unit beforehand.
