10
String Clamp Installation
The post of the String Clamp and tube of
the String Clamp Base may be treated with
grease to provide protection against corro-
sion during shipping and while in storage.
Remove any excessive grease with a clean
cloth prior to use. The post and tube may
also be cleaned with isopropyl alcohol. After
this type of thorough cleaning, the post and
tube should be treated with a light coating of
machine oil to protect the surfaces against
corrosion and to ensure smooth operation.
Turntable and Mounting System Installation
To install the Turntable position the Turntable over the turntable pin and align the holes in the
turntable with the holes in the turntable pin. Insert the bolts through the holes in the turntable
and turntable pin and tighten with an M6 hex wrench.
ASSEMBLY INSTRUCTIONS
STRING CLAMP INSTALLATION
