Here are the detailed procedures to make the charger work. All the screens
and operations will take LiPo-CHARGE program for example
Connection
Ensure to connect the battery to balance port when charging LiPo,Lilon, LiFe and LiHV battery
under balance mode.
OPERATION PROGRAM
1).Connecting to Power Source
2) Connecting e Battery
3).Balance Socket
Gannet Charger comes with the built in switching power supply. You can connect the AC power
cord directly to the main AC socket (100-240V AC) or attaching directly to 12V car batteries. It
is critically important that you use a fully charged 13.8V car battery.
Important!!! Before connecting a battery it is absolutely essential to check one last time that you
have set the parameters correctly. If the settings are incorrect, the battery may be damaged, and
could even burst into ames or explode.
To avoid short circuits between the banana plugs, always connect the charge leads to the charger
rst, and only then to the battery. Reverse the sequence when disconnecting the pack.
e balance wire attached to the battery must be connected to the charger with the negative
marking. Take care to maintain correct polarity!(See the wiring diagram below.)
is diagram shows the correct way to connect your battery to the AC while
charging in the balance charge program mode only.
