GANSHORN PowerCube-Ergo - Chapter 7: Spare Parts List; Gas Analyzers and Electromechanical Spares; PCBs and Mechanical Components; Cables, Tubes, and Housing Parts

GANSHORN Medizin Electronic GmbH Service Manual Ref.No. 03 140 0 046
PowerCube-Ergo-CASE_ENG_rev.02, 23.11.2012 Chapter 7, Spare Parts, page 1 of 2
Chapter 7: Spare Parts
Spare Part List PowerCube-Ergo-SSO (GE CASE-ES)
GE Ref.No.
Gas analyzers (for exchange only, please send back the original parts)
2044244-001
O2-Analyzer (SSO) PowerCube-Ergo (incl. assembly auxiliaries)
2044244-002
CO2-Analysator PowerCube-Ergo (incl. assembly auxiliaries)
Electromechanical parts
2044244-003
Side-stream sampling pump MB for PowerCube-Ergo
2044244-004
Calibration valve incl. PVC-tube 2x1 (20 cm) and two attached connection
tubes (KP7011) for PowerCube-Ergo (incl. assembly auxiliaries)
PCBs (for exchange only, please send back the original parts)
2044244-005
Analoge Module PowerCube-Ergo-SSO (incl. assembly auxiliaries)
2044244-006
Controller Module PowerCube-Ergo incl. DCDC-Module and PIC
(incl. assembl.aux.)
2044244-036
Anacom Module SPO2
Mechanical parts
2044244-007
Electronic unit holder PowerCube (PU: 2) (incl. assembly auxiliaries)
2044244-008
Mounting plate PowerCube-Ergo/Body/Diff (incl. assembly auxiliaries)
2044244-009
Compensation vessel PowerCube-Ergo/Body/Diff
2044244-010
Stands for PowerCube (PU: 4)
Internal cables
2044244-011
Internal cable set incl. power switch (KP7001) for PowerCube
(incl. assembl.aux.)
2044244-012
External RS232 cable, 2 m (KP7003) for PowerCube
(incl. assembly auxiliaries)
2044244-013
Connection cable CO2-Analysator (KP7004) for PowerCube-Ergo
(incl. assembl.aux.)
2044244-014
Internal temperature sensor (KP7005) for PowerCube
(incl. assembly auxiliaries)
2044244-015
Internal equalization cable cover (KP7008) for PowerCube
2044244-016
Internal electronic unit pulse receiver (KP7009) for PowerCube-Ergo
(incl. assembly auxiliaries)
2044244-017
Internal electronic unit SPO2 (KP7139) for PowerCube-Ergo-SPO2
2044244-018
Internal connection cable AnaCom-Module - Analog-Module (KP7014)
for PowerCube-Ergo-SPO2
2044244-019
Internal equalization cable mounting plate (KP7018) for PowerCube
2044244-020
Internal equalization cable housing (KP7019) for PowerCube
2044244-021
Connection cable SSO-Sensor - Controller-Module(KP7039) for PowerCube-
Ergo-SSO
2044244-022
Connection cable SSO-Signal Controller-Module / Analog-Module (KP7040)
for PowerCube-Ergo-SSO
2044244-036
Internal connection cable RS232 (KP7002)
Internal tubes
2044244-023
Internal flow-tubing set (SP7001) for PowerCube with pneumotach
2044244-024
Internal gas calibration tubing set (SP7006) for PowerCube-Ergo A1, B1
2044244-025
Internal measurement tubing set ergospirometry (SP7025)
for PowerCube-Ergo-SSO
Other spare parts
2044244-026
Complete housing, GE-health for PowerCube-Ergo-SSO, (incl. assembl.aux.)
2044244-027
Complete housing, GE-health for PowerCube-Ergo-SSO-SPO2,
(incl. assembl. aux.)
2044244-028
Cover, standard blue (RAL 5013) for PowerCube-Ergo-SSO
(incl. assembl.aux.)
2044244-029
Front panel PowerCube, standard blue
2044244-030
Rear panel PowerCube-Ergo/Spiro, standard blue
2044244-031
External temperature sensor 6 cm (KP7006) for PowerCube
2044244-032
External temperature sensor 70 cm (KP7026) for PowerCube
2044244-033
Power supply PwC 100–240VAC, 24VDC,
