Gardena 19005 - Initial Operation

3. INITIAL OPERATION
Contents:
– Gateway unit
– Power supply unit
– Ethernet-cable
To mount on the wall (optional):
The two screws (not supplied) for attaching the Gateway have to be screwed
into place A horizontally 75 mm / B vertically 50 mm apart and the screw head
diameter must not exceed 8 mm.
75 mm
A
50 mm
B
1. Screw the screws into the wall A 75 mm / B 50 mm apart.
2. Attach the Gateway.
6
EN
