Gardena smart Gateway - Optional Wall Mounting

To mount the Gateway on the wall (optional):
The two screws (not supplied) for attaching the Gateway have to be screwed
into place A horizontally 75 mm / B vertically 50 mm apart and the screw head
diameter must not exceed 8 mm.
75 mm
A
50 mm
B
1. Screw the screws into the wall A 75 mm / B 50 mm apart.
2. Attach the Gateway.
