Gardenline DF-003 - Step 12: Attach Side Burner and Shelf

Step 12: Attach Side Burner and Shelf
30
32
33
12
1. Attach the side burner 30 to the left legs. Connecting elements: 4 × Step Screw
GG .
2.
Attach the hooks
33 to the front of the foldable shelf 32 . 3 × Screw M6×12 HH.
3.
Attach the foldable shelf
32 to the right legs. Connecting elements: 4 × Step
Screw GG .
4. Mak
e sure all nuts and bolts are fully tightened.
Assembly instruction
22
